Cable specification

16A/1Phase – 3.5KW – 3×2.5mm²+2×0.5mm²
32A/1Phase – 7KW – 3×6.0mm²+2×0.5mm²
16A/3Phase – 11KW – 5×2.5mm²+2×0.5mm²
32A/3Phase – 22KW – 5×6.0mm²+2×0.5mm²

Mechanical life

No-load plug in / pull out > 10,000 times

Plug dimensions

L210 x W69 x H62 (mm) / L220 x W65 x H64 (mm)

Protection rank

IP55

Work temperature

-30°C~+50°C

Materials

EV charging cable TPU

Case material

Thermoplastic(flame retardant grade UL94-0)

Certification

CE / UKCA / RoHS
